Description :

APPLICATIONS
1. Electric fan
2. Heater
3. Electric timers.
4. Air Conditioner
5. Other

Specification :

1. Setting time(MAX) : 2.4/2H, 3.6/3H, 4.8/4H, 6/5H, 7.2/6H, 9.6.8H, 12/10H, 14.4/12H
2. Rated Voltage : AC 100V, 110V~125V, 220V~240V
3. Power Frequency : 50/60 Hz
4. Contact Capacity :
* AC 125V 15A
* AC 250V 7.5A
5. Working angle : 270°, 360 °
6. Working temperature : -10 ~ 60°C
7. Time Tolerance : + / - 6%
8. Continuous-ON : Free for need

Features :

1. It would cut the power and stop the control system, when working time to be ended.
2. Long period time setting, high performance.
3. Single Current System, ON-OFF.
4. Nicely precise construction to minimize the operation trouble to almost zero.
5. Have continuous-ON Current System.

•
